Low surface energy PET double-sided adhesive tape

Double Sided PET tape is made of PET film as the base material and coated with special acrylic pressure-sensitive adhesive on both sides. It has excellent adhesion, good Initial Tack and stickiness, good high humidity resistance, excellent aging resistance, excellent high and low temperature shear resistance, strong Tensile Strength and other characteristics.

Request A Quote


1. Used for pasting of backlight modules, fixing and pasting of electronic and electrical components, dust-proof nets, LED reflection molds and other parts.

2. Bonding and fixing of nameplates and membrane switches in the home appliance industry.

3. Paste and fix FPC.

4. Paste and fix the internal structure of OLED.

5. The module is fixed by pasting the protective film.

6. Temporary fixing and pasting of mobile phone parts.

7. Paste the graphite sheet inside the mobile phone.

8. Paste and fix the rubber feet.

9. Paste the sprayed board on the mesh surface of the microwave oven door.


Product Code Color Total Thickness [um] Backing [mm] Adhesive Initial Tack
180°Peel Strength
Long-Term Temperature Resistance [℃] Short-Term Temperature Resistance [℃]
P3215A Transparent 150 0.012 Acrylic ≥100 ≥20 ≥24 80 120
P3217A Transparent 170 0.012 Acrylic ≥50 ≥20 ≥24 80 120


Low Surface Energy PET Double-Sided Adhesive Tape uses PET film as the base material and is coated on both sides with an adhesive specially designed for low surface energy materials. This adhesive provides excellent wetting and adhesion to form strong bonds on low surface energy materials. At the same time, the excellent properties of PET substrate also give the tape good insulation, high temperature resistance and chemical stability.
Low Surface Energy PET Double-Sided Adhesive Tape is a tape product specially designed for low surface energy materials. It has a wide range of application scenarios, including:

1. Bonding of plastic and rubber products: Due to its special adhesive formula, this tape can firmly adhere to low surface energy plastics and rubber, such as PP, PE, silicone and other materials, and is often used Temporary fixing during manufacturing or final assembly.
2. Pasting of car interiors: Many parts inside cars, such as dashboards, door panels, seats, etc., are often made of low surface energy materials. This tape easily handles the application of these materials, ensuring interior components are secure and reliable.
3. Assembly of electronic products: In the manufacturing process of electronic products, components with low surface energy need to be fixed frequently. Low Surface Energy PET Double-Sided Adhesive Tape's high adhesion and stability make it play an important role in the assembly of electronic products.
4. Decoration and fixation of special surfaces: For low surface energy materials such as glass, ceramics, marble, etc., traditional tapes often fail to provide sufficient adhesion. This kind of tape can easily meet these challenges and provide a reliable solution for the decoration and fixation of special surfaces.

Size and color
Low Surface Energy PET Double-Sided Adhesive Tape is available in various sizes and specifications and can be customized according to customer needs. Common width specifications range from a few millimeters to tens of millimeters, and the length can be cut according to specific application scenarios. In terms of thickness, the thickness of the tape varies depending on the usage scenario, ranging from a few microns to hundreds of microns.
In terms of color, this kind of tape is usually transparent or light-colored, which can not only maintain the original appearance of the object being pasted, but also facilitate users to observe and adjust during use.

Specification data
